Name: 2022 Trek Émonda SL 5 Disc Road Bike
Brand: Trek
Price: 1860.00 USD
Availability: InStock

2022 Trek Émonda SL 5 Disc Road Bike

Top Brand

Description
Reviews

2022 TREK ÉMONDA SL 5 DISC

Frame	Ultralight 500 Series OCLV Carbon, Ride Tuned performance tube optimization, tapered head tube, internal routing, DuoTrap S compatible, flat mount disc, 142x12mm thru axle
Fork	Émonda SL full carbon, tapered carbon steerer, internal brake routing, flat mount disc, 12x100mm thru axle
Frame fit	H1.5 Race
Hub front	Bontrager alloy, sealed bearing, centerlock disc, 100x12mm thru axle
Skewer front	Bontrager Switch thru axle, removable lever
Hub rear	Bontrager alloy, sealed bearing, centerlock disc, Shimano 11-speed freehub, 142x12mm thru axle
Skewer rear	Bontrager Switch thru axle, removable lever
*Rim	Size: 47, 50, 52, 54, 56, 58, 60, 62 Bontrager Affinity Disc, Tubeless Ready, 24-hole, 21mm width, presta valve
*Rim	Size: 47, 50, 52, 54, 56, 58, 60, 62 Bontrager Paradigm SL, Tubeless Ready, 24-hole, 21mm width, presta valve
Spokes	14g stainless steel
Tire	Bontrager R1 Hard-Case Lite, wire bead, 60 tpi, 700x28c
Max tire size	30c
*Shifter	Size: 47, 50, 52 Shimano 105 R7025, short-reach lever, 11 speed
*Shifter	Size: 54, 56, 58, 60, 62 Shimano 105 R7020, 11 speed
Front derailleur	Shimano 105 R7000, braze-on
Rear derailleur	Shimano 105 R7000, short cage, 30T max cog
*Crank	Size: 47 Shimano 105 R7000, 50/34 (compact), 165mm length
	Size: 50, 52 Shimano 105 R7000, 50/34 (compact), 170mm length
	Size: 54, 56, 58 Shimano 105 R7000, 50/34 (compact), 172.5mm length
	Size: 60, 62 Shimano 105 R7000, 50/34 (compact), 175mm length
Bottom bracket	Praxis, T47 threaded, internal bearing
Cassette	Shimano 105 R7000, 11-30, 11 speed
Chain	Shimano 105 HG601, 11 speed
Max chainring size	1x: 50T, 2x: 53/39T
*Saddle	Size: 47, 50, 52 Bontrager P3 Verse Comp, steel rails, 155mm width
*Saddle	Size: 54, 56, 58, 60, 62 Bontrager P3 Verse Comp, steel rails, 145mm width
*Seatpost	Size: 47, 50, 52, 54 Bontrager alloy seatmast cap, 10mm offset, short length
*Seatpost	Size: 56, 58, 60, 62 Bontrager alloy seatmast cap, 10mm offset, tall length
*Handlebar	Size: 47, 50 Bontrager Comp VR-C, alloy, 31.8mm, 100mm reach, 124mm drop, 38cm width
	Size: 52 Bontrager Comp VR-C, alloy, 31.8mm, 100mm reach, 124mm drop, 40cm width
	Size: 54, 56, 58 Bontrager Comp VR-C, alloy, 31.8mm, 100mm reach, 124mm drop, 42cm width
	Size: 60, 62 Bontrager Comp VR-C, alloy, 31.8mm, 100mm reach, 124mm drop, 44cm width
Handlebar tape	Bontrager Supertack Perf tape
*Stem	Size: 47 Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 70mm length
	Size: 50 Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 80mm length
	Size: 52, 54 Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 90mm length
	Size: 56 Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 100mm length
	Size: 58, 60, 62 Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 110mm length
Brake	Shimano 105 hydraulic disc, flat mount
Brake rotor	Shimano SM-RT70, centerlock, 160mm
