2024 MERIDA SCULTURA TEAM SPECIFICATION SPECIFICATION

Frame	SCULTURA TEAM III CF5 V, 700x28C max, PF86, DISC
Color	RED/BLACK (TEAM)
Fork	SCULTURA TEAM III CF5 disc, 100x12 mm width front hub, 1.5" taper, flat mount, DISC
Headset	FSA ACR
Bottom Bracket	Shimano Pressfit SM-BB92-41B, Pressfit 86.5
Handlebar	Vision Metron 5D ACR Carbon, 400 mm-XXS/XS, 420 mm-S, 420 mm-M, 440 mm-L/XL
Stem	Vision Metron 5D ACR Carbon
Seatpost	MERIDA TEAM SL, Carbon, Aero shape, 15 mm setback, S-Flex
Saddle	Prologo Scratch M5 Nack
Rear Derailleur	Shimano Dura Ace Di2
Front Derailleur	Shimano Dura Ace Di2
Crank	Shimano Dura Ace, 52-36 teeth, Power Meter, 165 mm-XXS, 170 mm-XS, 172.5 mm-S/M, 175 mm-L/XL
Power Meter	Shimano Dura Ace, 52-36 teeth, Power Meter, 165 mm-XXS, 170 mm-XS, 172.5 mm-S/M, 175 mm-L/XL
Shifters	Shimano Dura Ace disc Di2
Cassette	Shimano CS-R9200, 11-30 teeth, 12 speed
Chain	Shimano CN-M9100-12
Brakes	Shimano Dura Ace, Hydraulic disc Type: Shimano Dura-Ace Hydraulic Disc
Brake Levers	Shimano Dura Ace disc
Rims	Vision Metron 45 SL Clincher TL Disc, 100x12 mm front hub, 142x12 mm rear hub, 21 mm inner width, 45 mm height, Centerlock, carbon, tubeless ready (tubeless tape and valves included)
Front Hub	MERIDA EXPERT SL, including removable lever, 6/4 mm allen key
Rear Hub	MERIDA EXPERT SL, including removable lever, 6/4 mm allen key
Tires	Front: Continental Grand Prix 5000S TR, 700x28C, fold, tubeless ready Rear: Continental Grand Prix 5000S TR, 700x28C, fold, tubeless ready
Disc Rotors	Shimano CL900, 160 mm, 140 mm
