Canyon Ultimate CFR, Pro-level build of our latest 5th-generation Ultimate frame delivering the pinnacle of stiffness-to-weight. As raced at World Tour level., Axle dimension: 12x142 mm, Tyre clearance: 33 mm, Material: Carbon (CFR), Weight: 835 g
BB Standard: BB86/BB92, 86mm, Press Fit Tire Clearance: 33c Colors: Sparkle Stealth; Movistar Stealth; Funky Diamond
Fork
Canyon FK0108 CFR, Superlight carbon fork, engineered for maximum stiffness-to-weight and compliance., Axle dimension: 12x100 mm, Fork steer tube diameter: 1 1/4", Tyre clearance: 33 mm, Material: Carbon (CFR), Weight: 376 g
Selle Italia SLR Boost 3D KIT Carbonio Superflow, Width: 130 mm, Gender: Unisex, Max. Rider Weight: 100 kg, Weight: 163 g
Seatpost
Canyon SP0064, Superlight custom carbon seatpost with aerodynamic D-shape profile., Setback: 0 mm, Weight: 70 g, Material: Carbon (CF), Weight: 70 g
Type: Rigid
Pedals
None included
Rims
DT Swiss ARC 1100 Dicut db, Axle dimension: 12x100 mm, Rotor mount: Center Lock, Rim height: 38 mm, Inner width: 20 mm, Rim material: Carbon, Weight: 587 g | DT Swiss ARC 1100 Dicut db, Axle dimension: 12x142 mm, Rotor mount: Center Lock, Rim height: 38 mm, Inner width: 20 mm, Rim material: Carbon, Weight: 712 g
Tires
Pirelli P Zero Race TLR, Width: 28 mm, Weight: 313 g
Disc Rotors
Shimano Dura-Ace RT-CL900, Size: 140 mm, Weight: 94 g | Shimano Dura-Ace RT-CL900, Size: 160 mm, Weight: 113 g
Shimano Dura-Ace Di2 R9200 Powermeter, Number of chainrings: 2
Power Meter
Shimano Dura-Ace Di2 R9200 Powermeter
Shifters
Shimano Dura-Ace Di2 R9270, 12-speed, Number of pistons: 2, Weight: 332 g | Shimano Dura-Ace Di2 R9270, 12-speed, Number of pistons: 2, Weight: 330 g
Cassette
Shimano Dura-Ace R9200, 12-speed, 11-34, Number of sprockets: 12, Range: 11-34
Chain
Shimano CN-M9100 12s
Brakes
Shimano Dura-Ace Di2 R9270, 12-speed, Number of pistons: 2, Weight: 332 g | Shimano Dura-Ace Di2 R9270, 12-speed, Number of pistons: 2, Weight: 330 g
Type: Shimano Dura-Ace Hydraulic Disc
Brake Levers
Shimano Dura-Ace Di2 R9270, 12-speed, Number of pistons: 2, Weight: 332 g | Shimano Dura-Ace Di2 R9270, 12-speed, Number of pistons: 2, Weight: 330 g
