2025 SCOTT SPARK RC COMP BIKE SPECIFICATION

Frame	Spark RC Carbon HMF Integrated Suspension Technology Flex Pivot / Adjustable head angle Syncros Cable Integration System BB92 / UDH Interface / 12x148mm with 55mm Chainline
Fork	FOX 32 Float Rhythm Grip 3-Modes / Kabolt 15x110mm axle / 44mm offset / tapered steerer Reb. Adj. / Lockout / 120mm travel
Rear Shock	FOX Float LV Custom EVOL Performace Trunnion 3 modes / Lockout-Trail-Descend DPS / Reb. Adj. Travel 120mm / T165X45mm
Remote System	SCOTT TwinLoc Technology 3 Suspension modes
Rear Derailleur	SRAM NX Eagle 12 Speed
Shifters	SRAM NX Eagle Trigger
Crankset	SRAM NX Eagle DUB 55mm CL / 32T
Chainguide	SCOTT custom
BB-Set	SRAM DUB PF 92 MTB Wide / shell 41x92mm
Chain	SRAM CN NX Eagle
Cassette	SRAM SX-PG1230 / 11-50
Brakes	Shimano Deore M6100 Disc
Rotor	Shimano SM-RT64 / CL / 180/F and 160/R
Handlebar	Syncros Fraser 2.0 XC Alloy 6061 D.B. Flat Bar / 8° / 740mm Syncros Performance XC lock-on grips
H'stem	Syncros XC 2.0 Syncros Cable Integration System -12° rise / 6061 Alloy / 31.8mm / 1 1/8"
Seatpost	Syncros Duncan 2.0 / 10mm offset 31.6x400mm
Seat	Syncros Belcarra Regular 2.0 CRMO rails
Headset	Syncros - Acros Angle adjust & Cable Routing HS System +-0.6° head angle adjustment ZS56/28.6 – ZS56/40 MTB
Hub (Front)	Formula CL-811 / 15x110mm
Hub (Rear)	Formula CL-148S / 12x148mm Syncros Axle w/Removable Lever with 6mm Allen T30 and T25 Tools
Spokes	Stainless Black 15G / 1.8mm
Rims	Syncros X-30SE / 32H / 30mm Tubeless ready
Front Tire	Maxxis Rekon Race / 29x2.4" / 60TPI Foldable Bead Tubeless Ready / EXO
Rear Tire	Maxxis Rekon Race / 29x2.4" / 60TPI Foldable Bead Tubeless Ready / EXO
