2025 TREK FUEL EX 9.8 GX AXS T-TYPE GEN 6 SPECIFICATION

Frame	OCLV Mountain Carbon, internal storage, angle-adjust headset, Mino Link adjustable geometry, adjustable leverage rate, guided internal routing, magnesium rocker link, 34.9mm seat tube, ISCG 05, 55mm chainline, BSA 73, downtube guard, shuttle guard, ABP, UDH, Boost148, 140mm travel BB Standard: BSA, 73mm, Threaded Hanger Standard: UDH Tire Clearance: 2.5" Colors: Deep Smoke; Lava
Fork	Fox Performance 36, Float EVOL air spring, GRIP damper, tapered steerer, 44mm offset, Boost110, 15mm Kabolt axle, 150mm travel Travel: 150mm Spring Type: Air
Shock	Fox Performance Float X, 2-position damper, 185mm x 55mm Travel: 140mm
Bottom Bracket	SRAM DUB MTB Wide, 73mm, BSA threaded
Headset	Integrated cartridge bearing, 1-1/8" top, 1.5" bottom, angle adjust cup compatible
Saddle	Size: XS, S, M, ML, L, XL, Bontrager Arvada, austenite rails, 138mm width; Size: XS, S, M, ML, L, XL, Verse Short Comp, steel rails, 145mm width
Seatpost	Size: XS, S, Bontrager Line Elite Dropper, 100mm travel, MaxFlow, internal routing, 34.9mm, 345mm length; Size: XS, S, Bontrager Line Dropper, 100mm travel, MaxFlow, internal routing, 34.9mm, 310mm length; Size: M, ML, Bontrager Line Elite Dropper, 150mm travel, MaxFlow, internal routing, 34.9mm, 440mm length; Size: M, Bontrager Line Dropper, 150mm travel, MaxFlow, internal routing, 34.9mm, 410mm length; Size: ML, L, XL, Bontrager Line Dropper, 170mm travel, MaxFlow, internal routing, 34.9mm, 450mm length; Size: L, Bontrager Line Elite Dropper, 170mm travel, MaxFlow, internal routing, 34.9mm, 485mm length; Size: XL, Bontrager Line Elite Dropper, 200mm travel, MaxFlow, internal routing, 34.9mm, 550mm length Type: Dropper
Grips	Bontrager XR Trail Elite, nylon lock-on
Rear Derailleur	SRAM GX Eagle AXS, T-Type
Crank	SRAM GX Eagle, T-Type, DUB, 30T, 55mm chainline, 170mm length
Shifters	SRAM AXS POD
Cassette	SRAM Eagle XS-1275, T-Type, 10-52, 12 speed
Chain	SRAM GX Eagle, T-Type, 12 speed
Brakes	SRAM CODE Bronze 4-piston hydraulic disc Type: SRAM Hydraulic Disc
Rims	Bontrager Line Elite 30, Tubeless Ready
Front Hub	Bontrager alloy, sealed bearing, alloy axle, 6-bolt, Boost110, 15mm thru axle
Tires	Size: XS, S, Bontrager SE5 Team Issue, Tubeless Ready, Core Strength sidewalls, aramid bead, 120 tpi, 27.5x2.50"; Size: S, M, ML, L, XL, Bontrager SE5 Team Issue, Tubeless Ready, Core Strength sidewalls, aramid bead, 120 tpi, 29x2.50"
Disc Rotors	Size: XS, S, M, ML, L, XL, SRAM CenterLine, 6-bolt, round edge, 180mm; Size: M, ML, L, XL, SRAM CenterLine, 6-bolt, round edge, 200mm
